ClearPath™ Sleeve
Introduction
The ClearPath™ Sleeve is a non-rotating stabilizer sleeve that gives you 360° wellbore contact through six to eight stabilizing points.
Fore-and-aft stabilization keeps the assembly centered throughout the run. Full wellbore engagement cuts vibration, extends sleeve life, and supports higher ROP. Low-friction, dome-shaped blades reduce torque and drag, while a hydrodynamic recess profile keeps cuttings moving past the tool.
Every sleeve is bespoke. Taper angle, blade contact area, and fluid bypass area are designed around your specific operation.
Consistent Hole Contact
Six to eight stabilizing points hold the assembly centered from spud to total depth, in mud motor and directional assemblies alike.
Reduced Torque and Drag
Low-friction, dome-shaped blades and optimized taper angles improve sliding yields in deviated and high-torque wells.
Designed Around your Well
Blade contact area and fluid bypass area are configured to your operational needs, not fixed to a catalog spec.
How It Works
Contact Without the Wear
A sleeve under constant wellbore contact takes on vibration, torque, and drag with every rotation. Left unmanaged, that wear shortens sleeve life and slows the run.
The ClearPath™ Sleeve spreads that load across six to eight discrete stabilizing points instead of a continuous spiral blade. Low-friction, dome-shaped blades and optimized taper angles reduce the friction at each point, while a hydrodynamic recess profile keeps cuttings clearing past the tool rather than packing around it.
The result is consistent hole contact for the length of the run: less vibration, longer sleeve life, and higher ROP, with sliding yields improved by the reduced torque and drag.
ClearPath™ Videos
4 Design Changes That Help You Slide Further | ClearPath
Keep Flow Rates Below Frac With a Better RSS Sleeve | ClearPath
Cleaner Hole, Lower Pressure Drop: RSS Sleeve in 60 Seconds
